Product Details:
|
|
| Place of Origin: | Made in China |
|---|---|
| Brand Name: | Btutest |
| Certification: | SGS, INTERTEK |
| Model Number: | FY-618 |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 set |
| Price: | Negotiable |
| Packaging Details: | Cement Testing Equipment Standard export wooden box |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 3000 sets per month |
|
Detail Information |
|||
| Name: | Mortar Mixer Semi Automatic Cement Testing Equipment | Warranty: | 1 Year |
|---|---|---|---|
| Standard: | EN 196-1 EN 196-3 EN 413-2 EN 459-2 EN 480-1 DIN 1164-5 ASTM C305 AASHTO T162 | The Maximum Power Is: | 200W |
| Voltage Input: | 220V | Net Weight: | 70kg |
| High Light: | Mortar Mixer Machine 200W,Hydraulic Mortar Mixer EN 196-1 |
||
Product Description
Mortar Mixer Semi Automatic Cement Testing Equipment
Standard:
EN 196-1 EN 196-3 EN 413-2 EN 459-2 EN 480-1 DIN 1164-5 ASTM C305 AASHTO T162
Description:
Fy-618 hydraulic mortar mixer is an experimental instrument for testing the strength of cement mortar. It can also be used as a mixer for gb177-85 cement mortar strength test method instead of gb33501-82, and can also be used as a slurry and mortar mixer for cement test.Cement Testing Equipment.
This machine is used for cement testing in cement plants, construction units, relevant universities and scientific research units.
Specification:
| Rotation number of mixing blade R / min : Low speed 140 ± 5 62 ± 5 , high speed 285 ± 10 125 ± 10 |
| The movement track of the stirring blade in the rotating pot is the same as that specified in ISO679-1989 (E). |
| Width of mixing blade: 135mm |
| The connecting thread between the mixing blade and the mixing blade shaft is M18×15 |
| Stirring pot solvent 5L, wall thickness 1.5mm |
| The working clearance between the mixing blade and the mixing pot is 3 ± 1mm |
| The motor is a horizontal split power two speed DC permanent magnet motor. |
| The maximum power: 200W |
| Voltage input: 220V |
| Overall dimension: 600×320×600(mm) l * w * h |
| Net weight: 70kg |
About Us:
260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS & INTERTEK certificated, one hour reach Tianjin port, this is how we keep good quality and competitive prices for global valued customers.
Our main products cover Universal testing machine, Compression testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks, Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids, Geotextiles, Textiles, Environmental,General Equipment,Cement Testing Equipmentt.BTUTEST is exporting its products to more than 60 countries by offering its services through its authorized distributors and representatives.
Our main customers are private and research testing laboratories, road and general contractors, concrete and cement manufacturers, asphalt manufacturers, government authorities, ministries, engineers, consultants and re-seller. We also cooperate with accredited research centers and the most important universities in the world.we can supply more top quality product and service for more customer’s.
Our Advantage:
Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.
Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to video for you.
Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16 years focusing on test instruments field. warmly welcome to visit our plant (factory), we also support OEM and ODM.
Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange shipment within 7 days. Please be aware that our production lead times depend on specific items and item quantities.
Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional after-sale service team will provide perfect technical support. And help the customer solve problems encountered while using our product, handles problems and complaints professionally and timely. Each instruments must be carried out 100% quality examination and test when shipping and delivery goods.
Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the standard exporting wooden case, which not only has good shock absorption, impact resistance, heat SSO has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.
