High Precision ISO 1522 Paint Testing Instruments Pendulum Damping Tester

Product Description

Pendulum Damping Tester High-Precision Paint Testing Equipment

Standard:

ISO 1522 GB/T 1730

Features:

◆ high precision precision machined pendulum needle, strong stability, ensuring the reproducibility and comparability of test data, comparable to imported similar products

◆ two test methods can be switched: K pendulum (Konig) or P pendulum (persaz)

◆ humanized LCD operation interface

◆ using electromagnet (bgd 508) or shutter wire (bgd 509) to release the pendulum needle, the test results are more accurate.

◆ uniquely designed lifting working platform, easy to fix the test plate, stable platform without shaking when the pendulum needle swings

◆ special customized level calibrator, high precision, convenient for customers to adjust the level

◆ suitable for test plates with different thickness from 0.1mm to 5.5mm

◆ automatic counting or timing and automatically stop the test when the deflection is as low as 3 ° (K Ö nig) or 4 ° (Persoz), respectively.

◆ use two photosensitive probes to record deflection

◆ the test result recording mode can be arbitrarily selected: timing or counting (or mutual conversion)

◆ plexiglass door cover greatly reduces data deviation caused by air circulation.

◆ attached calibration certificate

Description:

The swing bar hardness test is an international general method for testing the coating film hardness in the coating industry. Its principle is to support two stainless steel balls on the swing bar hardness tester on the dried coating and swing in a certain period. If the coating surface is softer, the swing spoke of the swing bar will decay faster (the shorter the swing time from one angle to another); On the contrary, the slower the attenuation.

There are three different types of pendulum: double pendulum, K Ö nig single pendulum and Persoz single pendulum. It is worth noting that there is no conversion relationship between the test results of the swing bar with different structure, mass, size and period, because the interaction between the swing bar and the coating also depends on the complex elasticity and viscosity of the coating. Therefore, when measuring the damping time of a certain paint film in the product standard, only one swing rod is required.

In addition, in order to obtain a reliable test data, the test should be carried out under the condition of controlling temperature and humidity without the influence of air flow, and the film thickness and substrate material can also affect the damping time.
